Micro Coupler
Compact, lightweight Cuplas with only
9.5 mm outer diameter.
Push-to-connect operation. Tube Fitter
type for even easier tube insertion.
Open E-Catalog
Description
Additional information
| Brand |
Nitto Kohki |
|---|
Related products
Hi Coupler
Universal purpose couplings for airlines
From factory airline to pneumatic tool connection, available in various body materials, sizes and end configurations. Excellent durability.
- An excellent general purpose coupling for connecting factory air supply to pneumatic tools.
- Steel coupling is suitable for air. Brass or stainless steel is suitable for water. Note that fluid will come out from the plug when disconnected.
- Critical structural parts of steel models are heat-treated for increased strength giving greater durability and resistance to wear.
- Available in various body materials, sizes and end configurations applicable to a wide range of applications
Open E-Catalog
Watch Video
Hi Coupler 200
Simple and secure push-to-connect type! Big flow rate! End-face seal design. Gives excellent handling touch.
- Just push the plug into the socket for simple ans secure connection.This reduces connection.This reduces connection time and improves efficiency.
- New value design for pressure loss to achieve flow rate increse
- End-face seal is achieved when connected.
- Enhanced operability with low connection resistence
- Available only with quick connect/disconnect tube filter type.
Open E-Catalog
Hi Coupler ACE
Lightweight plastic coupling with automatic safety lock for air line applications.
- The Weight is merely a quarter of steel Hi Cupla’s and smooth push-in connection is achieved.
- Automatic sleeve lock for safety operation.
- Less likely to damage painted or easily dented surfaces than metal couplings.
Open E-Catalog
Watch Video
Full Blow Coupler
Unique full-open gate type valve mechanism
realizes low pressure loss and high flow rate,
which reduces required source air volume.
The flow rate is increased by up to 40% more then that of conventional
Cuplas.
- During connection and disconnection the valve is closed, enabling connection/disconnection under zero line pressure.
- When the sleeve of socket is returned to its original position, the purge mechanism releases the residual air pressure in the plug, eliminating an unpleasant popping noise and a hose whip back motion on disconnection.
Open E-Catalog
Watch Video
450 Coupler
Metal-touch valve system with superior durability! Sleeve stopper mechanism gives secure connection.
- Cupla for higher working pressure up to 44.1 MPa
Open E-Catalog
210 Coupler
Standard hydraulic Cuplas for general purposes with a working pressure up to 20.6 MPa.
Low pressure loss, suitable for hydraulic equipment.
Features
1. For Hydraulic Pressures upto 210 Bar
2. Structure is designed to reduce pressure loss to the lowest and is best for hydraulic applications that need big flow rates
3. Both plug & socket have built-in automatic shut-off vlaves that prevent fluid outflow when disconnected
4. Easy to handle
Open E-Catalog
PCV Coupler
For connection to copper pipes
- Clamps direct on to a straight copper pipe eliminating unnecessary welding or flaring -1
- Withstands a vacuum of up to 1.3 x 10 Pa (when connected) making it possible to be used in leak testing, evacuation and refrigerant gas charge.
- Select from three standard types of seal materials to be used with fluids for air conditioner and refrigerator production lines. Many models to suit various pipe sizes.
Open E-Catalog
Multi Coupler
Simultaneously connects several ports securely in one operation! Greatly cuts cycle time in multiple ports replacement.
- Handles several ports at once.
- Simple manual lever action completes easy connection / disconnection.
- Two stage lever operation prevents Cupla from accidental dropping due to sudden detachment.
- Comes with lock mechanism to prevent accidental disconnection.
- Large flow equivalent to that of SP Cupla Type A.
- Two kinds of plates are available for each size.
- Automatic shut-off valves in both socket and plug prevent fluid spill out on disconnection.
